TECHNISCHE SPEZIFIKATIONEN
-
Motortyp
-
Liquid-cooled, 4-stroke 90° V-twin
-
Hubraum
-
749 cm³
-
Bohrung x Hub
-
85 x 66 mm
-
Kompressionsverhältnis
-
9.3:1
-
Ventilsteuerung
-
SOHC, 8 valves
-
Gemischaufbereitung
-
Fuel injection: ø34 mm x 2
-
Zündung
-
Battery & Coil (Transistorised ignition)
-
Anlasser
-
Electric
-
Maximale Leistung
-
37.3 kW {51 PS} / 6,750 rpm
-
Maximales Drehmoment
-
58.1 N•m {5.9 kgf•m} / 4,750 rpm
-
Getriebe
-
2-speed automatic with reverse
-
Endantrieb
-
Shaft 2WD/4WD
-
Bremse, vorne
-
Dual 200 mm discs with 2-piston calipers
-
Bremse, hinten
-
Enclosed wet multi-plate
-
Radaufhängung, vorne
-
Double wishbone with 5-way adjustable spring preload
-
Radaufhängung, hinten
-
Double wishbone with 5-way adjustable spring preload
-
Rahmentyp
-
Double cradle, high-tensile tubular steel
-
Nachlauf
-
10 mm
-
Federweg vorne
-
175 mm
-
Federweg hinten
-
189 mm
-
Reifen, vorne
-
AT 25 x 8-12
-
Reifen, hinten
-
AT 25 x 10-12
-
L x B x H
-
2,185 x 1,170 x 1,210 mm
-
Radstand
-
1,285 mm
-
Bodenfreiheit
-
228 Std Preload setting, 245 max preload setting mm
-
Tankinhalt
-
19 litres
-
Trockengewicht
-
312 kg | **Estimated Dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
-
Gewicht fahrfertig
-
333 kg
